Directly Turning Micro Alloyed Steel Chrome Plated Rods For Construction

Directly Turning Micro Alloyed Steel Chrome Plated Rods For Construction
Directly Turning Micro Alloyed Steel Chrome Plated Rods For Construction Directly Turning Micro Alloyed Steel Chrome Plated Rods For Construction

تصویر بزرگ :  Directly Turning Micro Alloyed Steel Chrome Plated Rods For Construction

جزئیات محصول:

Place of Origin: China
نام تجاری: HY
گواهی: ISO9001:2008

پرداخت:

Minimum Order Quantity: 1 tons
قیمت: Negotiation
Packaging Details: Anti rust oil to be applied on material and each rod to be packed in paper sleeve
Delivery Time: 30days
Payment Terms: T/T, L/C
Supply Ability: 30tons a day
توضیحات محصول جزئیات
Product: Micro alloy steel rod Supply condition: Hard chrome plating
Hard chrome thickness: 20 - 30 micron Surface roughness: Ra≤0.2micron and Rt≤2micro
Tensile strength: Not less than 750 Mpa Yield strength: Not less than 520 Mpa
برجسته:

chrome plated piston rod,microalloyed steels

,

microalloyed steels



Directly Turning Micro Alloyed Steel Chrome Plated Rods For Construction



Product Description


1. The micro alloy steel products are developed on the basis of proprietary technology of the control

    rolling and cooling for substituting quenched and tempered piston rods with a variety of mechanical

    performance requirements.
2. The mechanical property is correspond to quenched and tempered piston rods or over them and

    very uniform on the whole cross section.
3. Hardness is more uniform on the whole cross section than quenched and tempered piston rods

4. Turning performance is commensurate to quenched and tempered piston rods or be superior to them.
5. Micro alloy steel rod mainly used in mechanical manufacturing for the directly turning part of shaft
   and rod, ect
6. The processing period is shortened, and the productivity is enhanced and the occupied capital is
    reduced..
7. The processing cost is low, there is no need of quenched and tempered process and the second
    turning but the mechanical property is correspond to quenched and tempered piston rod



Detailed Description

1. MATERIAL: HY4700, HY4520

2. CHEMICAL COMPOSITION(%)

Material

C%

Mn%

Si%

S%

P%

V%

Ni

Cr%

Mo

Cu

HY4700

0.38-0.45

1.20 ~1.60

0.30~0.50

≤0.035

≤0.020

0.05~0.15

≤0.25

0.10~0.20

≤0.15

0.25

HY4520

0.40 ~0.48

0.80 ~1.40

0.15 ~0.35

≤0.035

≤0.035

≤0.15

≤0.25

≤0.25

≤0.15

≤0.25



3. MECHANICAL PROPERTIES


Material

MECHANICAL PROPERTIES

Surface hardness(HBW)

 Rm(MPa)

Rel(MPa)

A%

Z%

KU2(J)



HY4700

Φ35 - Φ100

900 - 1100

≥650

≥16

≥35

≥39

270-340

>Φ100 - Φ140

850 - 950

≥600

≥16

≥35

≥39

270-340

HY4520

Φ40 - Φ100

750 - 900

≥520

≥19

≥40

≥39

230-290

>Φ100~Φ140

750 - 900

≥520

≥17

≥35

≥39

230-290



















4. SUPPLY CONDITION
    Ground  and  chrome plated
5. CHROME THICKNESS
     20 to 30 micron
6 .SURFACE HARDNESS
     850-1150HV (vickers 100g)
7. STRAIGHTNESS
   ≤0.2MM/M

8. TOLERANCES ON DIA
     ISO f7 on the diameter
9.OVALITY
    Half of the tolerance ISO f7
10. SURFACE ROUGHNESS
     Ra≤0.2 micron and  Rt≤2 micron

11. CORROSION RESISTANCE
     Test in natural salt spray according to ASTM B 117-120hours
     Results evaluation according to ISO 4540 RATING 7-10

12.POROSITY
      Test according to ISO 1456/1458 and result yaluation according to ISO 4540 rating 8-10

13. WELDABILITY
     Good
14. PACKING
     Anti rust oil to be applied on material and each rod to be packed in paper sleeve

15. COHESION

     No craks,breaking or detaching after thermic shock(warming up at 300 celsius degrees

    and cooling in water)

16. CERTIFICATE
      All certificate related with material heat treatment and plating is required
