Length 1m - 8m Micro Alloyed Steel Rod For Mechanical Manufacturing

Length 1m - 8m Micro Alloyed Steel Rod For Mechanical Manufacturing
Length 1m - 8m Micro Alloyed Steel Rod For Mechanical Manufacturing Length 1m - 8m Micro Alloyed Steel Rod For Mechanical Manufacturing

تصویر بزرگ :  Length 1m - 8m Micro Alloyed Steel Rod For Mechanical Manufacturing

جزئیات محصول:

Place of Origin: China
نام تجاری: HY
گواهی: ISO9001:2008

پرداخت:

Minimum Order Quantity: 1 tons
قیمت: Negotiation
Packaging Details: Anti rust oil to be applied on material and each rod to be packed in paper sleeve
Delivery Time: 30days
Payment Terms: T/T, L/C
Supply Ability: 30tons a day
توضیحات محصول جزئیات
Name: Chrome piston rod Material: Micro Alloy Steel
Supply condition: Chrome plating Chrome thickness: 20 - 30 micron
Diameter: 35mm - 140mm Surface roughness: Ra≤0.2micron and Rt≤2micro
برجسته:

chrome plated steel rod,microalloyed steels

,

microalloyed steels


Length 1m - 8m Micro Alloyed Steel Rod For Mechanical Manufacturing



Product Description
1. ISO9001:2008, stable and uniform mechanical properties, the directly turning saves the logistics cost.
2. Save manufacturing expenses and avoid waste in the tempering process.
3. Shortened processing periods, enhance productivity and reduce the occupied capital
4. The mechanical property is correspond to quenched and tempered 42CrMo4, 40Cr and CK45 or over
    them and very uniform on the whole cross section.
5. It can be used for manufacturing injuection molding machine draglink, engineering machinery push
    rod and hydraulic prop with the feature that hardened and tempered steel mechanical property
    needless quenched and tempered process.
6. Production no quenched and tempered process meets the requirements of environmental protection

Detailed Description

1. MATERIAL: HY4700, HY4520

2. CHEMICAL COMPOSITION(%)

Material

C%

Mn%

Si%

S%

P%

V%

Ni

Cr%

Mo

Cu

HY4700

0.38-0.45

1.20 ~1.60

0.30~0.50

≤0.035

≤0.020

0.05~0.15

≤0.25

0.10~0.20

≤0.15

0.25

HY4520

0.40 ~0.48

0.80 ~1.40

0.15 ~0.35

≤0.035

≤0.035

≤0.15

≤0.25

≤0.25

≤0.15

≤0.25



3. MECHANICAL PROPERTIES


Material

MECHANICAL PROPERTIES

Surface hardness(HBW)

 Rm(MPa)

Rel(MPa)

A%

Z%

KU2(J)



HY4700

Φ35 - Φ100

900 - 1100

≥650

≥16

≥35

≥39

270-340

>Φ100 - Φ140

850 - 950

≥600

≥16

≥35

≥39

270-340

HY4520

Φ40 - Φ100

750 - 900

≥520

≥19

≥40

≥39

230-290

>Φ100~Φ140

750 - 900

≥520

≥17

≥35

≥39

230-290



















4. SUPPLY CONDITION
    Ground  and  chrome plated
5. CHROME THICKNESS
     20 to 30 micron
6. TOLERANCES ON DIA
     ISO f7 on the diameter
7. STRAIGHTNESS
   ≤0.2MM/M
8.OVALITY
    Half of the tolerance ISO f7
9 .SURFACE HARDNESS
     850-1150HV (vickers 100g)
10. SURFACE ROUGHNESS
     Ra≤0.2 micron and  Rt≤2 micron
11. COHESION

     No craks,breaking or detaching after thermic shock(warming up at 300 celsius degrees

    and cooling in water)
12. CORROSION RESISTANCE
     Test in natural salt spray according to ASTM B 117-120hours
     Results evaluation according to ISO 4540 RATING 7-10

13. WELDABILITY
     Good

14.POROSITY
      Test according to ISO 1456/1458 and result yaluation according to ISO 4540 rating 8-10
15. PACKING
     Anti rust oil to be applied on material and each rod to be packed in paper sleeve
16. CERTIFICATE
      All certificate related with material heat treatment and plating is required
